For combinations
- The FT_/D window is designed for installation in vertical combinations and is typically installed beneath a standard roof window “extending’’ the roof window down the roof.
- Manufactured in pine, vacuum impregnated and double coated with acrylic lacquer (FTL/D L3) or three time coated (FTU/D L3 -version) in white polyurethane varnish NCS SO502-Y (similar to RAL 9010).
- System of reinforced window structure topSafe.
- New glazing seal provides additional tightness in extreme weather conditions and reduces the micro-pulses of the cladding profiles during heavy rain.
- Handle positioned at the lower part of the sash for easy operation, with two opening points.
- Opening restrictor.
- Suitable for roof pitches between 15-90° (when fitted with correct flashing).
- Wide selection of accessories.
-
FTP/D L3
-
L3 - Safety double glazed unit. Toughened outer pane. Laminated inner pane. U value of window 1.3
-
High quality close-grain vacuum - impregnated redwood pine guaranteed to be knot-free
-
Double coated wood with ecological acrylic lacquer in natural colour
-
Suitable for roof pitches between 15-90°
FTP/D L3
- 1.3 W/m²K U-värde hela konstruktionen 1.1 W/m²K Glasets U-värde 35 dB Ljudisolering Rw 4HS-14-33.1T Glas typ argon Gasfyllning mellan glasen + Härdat ytterglas + Smutsavvisande glas + Laminerat innerglas twice Färglager four Tätningar + Vädringsläge Elegant Handtag
-
-
FTU/D L3
-
L3 - Safety double glazed unit. Toughened outer pane. Laminated inner pane. U value of window 1.3
-
High quality close-grain vacuum - impregnated redwood pine guaranteed to be knot-free
-
Double coated wood with ecological acrylic lacquer in natural colour
-
Suitable for roof pitches between 15-90°
FTU/D L3
- 1.3 W/m²K U-värde hela konstruktionen 1.1 W/m²K Glasets U-värde 35 dB Ljudisolering Rw 4HS-14-33.1T Glas typ argon Gasfyllning mellan glasen + Härdat ytterglas + Smutsavvisande glas + Laminerat innerglas triple Färglager four Tätningar + Vädringsläge Elegant Handtag
-
